Migration lookup reference

This page is the lookup reference for the Neptune DXP App Migration Wizard. It covers the migration pipeline summary, engineer action detail, analysis report categories, DDIC label fetch behavior, diagnostics file contents, generated output files, and support scope guidance. It is linked from the step-by-step guide and concept overview at the relevant points.

Migration pipeline summary

The following describes what the migration engine transforms automatically. All transformations are applied where the corresponding elements are present in the source app.

App structure and content

Element How it is handled

UI5 controls and component tree

Fully migrated; all standard sap.m. *, sap.ui. *, and Neptune control types

Object properties and attributes

Migrated; non-empty values only, matching Neptune DXP - Open Edition convention

Script and TypeScript resources

Inlined into the Neptune DXP - Open Edition object model

HTML fragments

Inlined into the Neptune DXP - Open Edition object model

Event scripts (Anonymous Function)

Fully migrated; handlers behave identically in OE

App-level stylesheet (CSS)

Mapped to Neptune DXP - Open Edition css field

App manifest

Mapped to Neptune DXP - Open Edition manifest field

UI5 control type resolution

Resolved from object data, live library tree, or built-in fallback map; the Analyze step flags any controls where resolution cannot be completed automatically

Translations

Element How it is handled

Classic app translations / i18n

SAP single-character language codes converted to BCP-47 locale strings and inlined per attribute

SAP data dictionary field label translations

For DDIC-bound technical fields (e.g. ~MATNR → "Material Number"), human-readable label translations are fetched directly from the SAP dictionary for the languages specified in Advanced Options. See DDIC label fetch behaviour for detail.

Back-end connectivity

Element How it is handled

Ajax ID logic

Rewritten as TypeScript; calls routed through the Neptune DXP - Open Edition proxy to the SAP back end. Review generated code post-migration if backend paths or authentication parameters differ between environments.

OData model bindings

Recreated to route through the Neptune DXP - Open Edition proxy; validate against the SAP back end post-migration

REST API bindings

Runtime wrappers generated so REST-bound controls continue to work; validate connectivity post-migration

Mock server data

Neptune DXP - SAP Edition MockServer setups converted to the Neptune DXP - Open Edition equivalent

Neptune DXP - Open Edition metadata defaults

Neptune DXP - Open Edition-specific fields that do not exist in Neptune DXP - SAP Edition are set on first save. These reflect current Neptune DXP - Open Edition best practices and are appropriate for the vast majority of migrated apps. They can be adjusted in the app settings if your deployment has specific requirements.

Neptune DXP - Open Edition field Default Purpose

compilerTarget

3

ES compilation target (modern)

useV2AppHandler

true

Modern Neptune DXP - Open Edition app handler

enableFileStorage

false

Enables server-side file storage for the app; disabled by default as Neptune DXP - SAP Edition apps do not use this feature

enableManifest

true (if manifest content present)

Enables the app-level manifest; set automatically if the source app includes manifest content

enableStylesheet

true (if CSS content present)

Enables the app-level stylesheet; set automatically if the source app includes CSS content

publicAccess

false

Controls whether the app is accessible without authentication; disabled by default to preserve authenticated access

roles

[]

Authorization roles — assign as needed post-migration

id, ver, status

Assigned by OE on save

Managed by Neptune DXP - Open Edition runtime

Engineer action reference

SAP-specific elements and analysis report categories

The Analyze step flags elements that require engineer decisions. The table below covers both the report categories an engineer will encounter and the recommended action for each.

Element / report category What it means Recommended action

Information

Non-blocking notes, e.g. Ajax IDs present in scripts

Review post-migration; Ajax logic is restructured automatically into TypeScript

SAPUI5 controls (sap.suite. *, sap.ui.comp. *)

Controls unavailable in OpenUI5; flagged in the Analyze report

Replaced with safe placeholders during migration so the app continues to load. Plan manual replacement with Neptune DXP - Open Edition-compatible equivalents.

Value Help controls

No direct Neptune DXP - Open Edition mapping; flagged in the Analyze report

Manual replacement required post-migration

API Factory controls

Flagged in the Analyze report

Manual replacement required post-migration

REST API objects

Neptune DXP - SAP Edition-proprietary REST API node types

Runtime wrappers generated automatically; validate connectivity against the SAP back end post-migration

OData sources

References to ABAP OData services

Bindings recreated to route through the Neptune DXP - Open Edition proxy; validate against the SAP back end post-migration

Cross-app dependencies (AppCache.Load / AppCache.Open)

Other Neptune DXP - SAP Edition apps referenced in scripts

The report lists each referenced app ID. Verify that each exists in Neptune DXP - Open Edition, or plan to migrate it, before testing navigation flows

Custom Components (appType: "C")

App type requiring handling beyond the wizard’s current scope

Additional manual steps required. Consult the README for migration-specific detail

Errors

Blocking issues preventing migration

Review the error detail in the report. Each error is described with its cause and must be resolved before the Migrate step can proceed.

Elements configured in Neptune DXP - Open Edition

The following areas are most effectively established using Neptune DXP - Open Edition’s native tooling after migration. They are a normal part of the post-migration development workflow:

  • UI5 JSON model definitions: configure in the Neptune DXP - Open Edition App Designer

  • Table column definitions: configure in the Neptune DXP - Open Edition App Designer

  • Global app settings: configure in the Neptune DXP - Open Edition app settings

  • New-style i18n attributes and content: configure in the Neptune DXP - Open Edition App Designer

  • Plugin and theme data: configure in the Neptune DXP - Open Edition App Designer

  • Authorization roles: empty by default on the migrated app; assign appropriate Neptune DXP - Open Edition roles

  • Header script: re-enter in the Neptune DXP - Open Edition app settings if present in the source app

  • Data bindings: re-configure in Neptune DXP - Open Edition if the source app used Neptune DXP - SAP Edition-specific data bindings

DDIC label fetch behaviour

When DDIC-bound technical field bindings are present in the source app, identified by the ~ prefix (e.g. ~MATNR) or (sapddic>_) patterns, the wizard can fetch human-readable label translations directly from the SAP data dictionary at migration time.

Binding pattern Fetch mechanism Requirement

~DATA_ELEMENT (e.g. ~MATNR, with optional ~H, ~S, ~M, ~L suffixes)

API Factory /NEPTUNE/CL_DR_LIB_DDIC_DTEL_X

The SAP system must have the required API Factory class available and configured with an appropriate policy. For more information, see Policy.

Access to data element metadata through the API Factory is typically not considered security-sensitive. For app migration scenarios, enabling the Unrestricted API Engine option in the API Factory allows the retrieval of data element texts without additional restrictions.

api factory policy on

(sapddic>_) bindings

App’s sapddic_<lang>.properties files

Files must be present in the source app

Fetched translations are written into the migrated app as RefDataElements_* keys. Failed fetches are non-blocking. The migration continues without the affected translations. Fetch errors are reported in the diagnostics file under pipeline.refDataElementErrors.

If a ~ binding fetch fails, verify that the SAP user running the migration has the /NEPTUNE/CL_DR_LIB_DDIC_DTEL_X API Factory in their policy before re-running the analysis.

Diagnostics file reference

The diagnostics file is a JSON snapshot of the full migration analysis, available for download after the Analyze step has run and also on failure during the Migrate step. It is the primary artefact to attach when raising a support ticket.

Contents

Field Contents

tool

Bridge package name, version, and wizard identifier

runtime

Wizard runtime mode and non-credential configuration. Passwords, usernames, and base URLs that may carry tokens are stripped before the file is written.

sourceApp

Neptune DXP - SAP Edition app metadata: application ID (APPLID), title, description, development class (DEVCLASS), UI5 version, and app type

sourceSystem

Verified Neptune DXP - SAP Edition system information: name, description, and DXP version

counts

Quick totals: objects, warnings, dependencies, external references, and Neptune DXP - SAP Edition-specific objects

warnings

Full warnings output — identical to what is shown in the analysis report

dependencies

Full cross-app dependency output — identical to what is shown in the analysis report

externalRefs

Full external references output — identical to what is shown in the analysis report

modelBindingsSendReceive

Neptune DXP - SAP Edition Send/Receive binding details for cross-page model wiring

modelBindingSnapshots

Binding snapshots for each model object

sourceData

The complete raw Neptune DXP - SAP Edition source app as received by the bridge, allowing Neptune Support to reproduce the mapping offline

mappedApp

The complete mapped Neptune DXP - Open Edition app output including all generated migration code

pipeline

Post-processing results: Neptune DXP - Open Edition-safe filter exclusions, structural transforms, generic model rewrite details, ref-data-element transform entries, Ajax/OData/REST/MockServer migration counts, and any non-fatal ref-data-element fetch errors

What is not included

The following are scrubbed before the file is written and are not present in any form:

  • Passwords

  • Usernames

  • Base URLs that may carry authentication tokens

Migration output files reference

After a successful migration, the following files are generated under the Resources tree in the Neptune DXP - Open Edition App Designer:

Resources/
└── __GENERATED_MIGRATION_CODE__/
    ├── README                        ← migration summary
    └── __AJAX_ID_MIGRATION__/
        └── (generated .ts files, one per Ajax ID group)

README

The README is both human- and machine-readable. It provides a structured summary of the full migration pipeline output for the specific app:

  • Elements transformed automatically

  • Elements excluded or replaced with placeholders, and the reason for each

  • Elements that require manual review or rework

  • Elements with no Neptune DXP - Open Edition equivalent, with guidance on how to approach them

Consult the README before making manual changes or using Naia Build to continue development. It provides the migration-specific baseline for all subsequent work.

Ajax ID TypeScript files

Each generated .ts file under AJAX_ID_MIGRATION wraps one group of Ajax ID calls as TypeScript functions routed through the Neptune DXP - Open Edition proxy to the SAP back end. Service paths and SAP system parameters are preserved from the source app.

In most cases no changes are needed if the remote system is correctly configured in Neptune DXP - Open Edition. Changes are required when:

  • Back-end service paths differ between the Neptune DXP - SAP Edition and Neptune DXP - Open Edition environments

  • Authentication parameters have changed

  • Service structures have been modified on the SAP back end

Support scope and self-service guidance

Work through the checklist below before raising a support ticket. Most post-migration issues are the result of expected manual rework or environment-specific configuration rather than migration defects.

Self-service checklist

1. Consult the README. The GENERATED_MIGRATION_CODE / README lists every element that requires review or manual rework specific to your migration. If a control, binding, or service is not behaving as expected, verify whether it is documented there before escalating.

2. Review the Analyze report. If an element was flagged during analysis, its post-migration behavior is expected — the report described the required action. Hard-coded Ajax calls, unmapped OData services, and SAPUI5 control placeholders are expected outputs for apps containing those elements, not migration defects.

3. Verify remote system configuration. Generated Ajax TypeScript, OData bindings, and REST wrappers all route through the Neptune DXP - Open Edition remote system proxy. If back-end calls are not resolving, confirm that the remote system is correctly configured in Neptune DXP - Open Edition, the SAP back end is reachable, and service paths have not changed between environments.

4. Check API Factory policy permissions. If DDIC field label translations are missing, verify that the SAP user has the /NEPTUNE/CL_DR_LIB_DDIC_DTEL_X API Factory in their policy. Failed fetches are non-blocking and are reported in the diagnostics file under pipeline.refDataElementErrors, not as visible errors in the wizard.

5. Validate in the Neptune DXP - Open Edition runtime. Some binding and connectivity issues are only visible at runtime. Test the migrated app end-to-end against your SAP back end before concluding that a migration error has occurred.

What constitutes a support case

Raise a support ticket if:

  • The wizard produces an error during the Analyze or Migrate step that is not described in the analysis report or README.

  • The migrated app structure is materially incomplete in a way not accounted for by the Analyze report, for example, objects or scripts present in the Neptune DXP - SAP Edition source app are missing from the migrated app and are not flagged as unsupported.

  • A generated migration output (Ajax TypeScript, OData binding, REST wrapper) produces incorrect or unexpected behavior after remote system configuration has been verified.

  • The wizard fails to connect to a correctly configured remote system.

When raising a ticket, attach the diagnostics file downloaded from the Analyze step. It contains the full source app, mapped output, pipeline results, and system metadata required for Neptune Support to reproduce and investigate the issue offline. Do not substitute screenshots of the analysis report for the diagnostics file. The JSON contains detail not visible in the UI.

What falls outside support scope

The following are expected outcomes of the migration process and are not support cases:

  • SAPUI5 controls replaced with placeholders: these require manual replacement with Neptune DXP - Open Edition-compatible equivalents as documented in the Analyze report.

  • Ajax, OData, or REST connections that require reconfiguration because service paths, authentication, or system topology differ between the Neptune DXP - SAP Edition and Neptune DXP - Open Edition environments.

  • Elements listed under Engineer action reference that are configured directly in Neptune DXP - Open Edition as part of normal post-migration development.

  • Naia Build output that requires manual adjustment for larger apps — expected behavior related to app complexity, as described in the step-by-step guide.

  • App behavior that differs from Neptune DXP - SAP Edition due to differences between SAPUI5 and OpenUI5, or between SAP back-end services and Neptune DXP - Open Edition-proxied equivalents.
